Design deciduous forest and grassland inventories

Last changed: 15 May 2024

To inventory both common and uncommon habitats within a general framework, a comprehensive sampling design has been developed for NILS inventories of alpine areas, grasslands, seashores, and deciduous forests. It is essentially a multi-stage sampling design that is customized for each specific inventory. The inventories, in particular the grassland and deciduous forest inventories, are closely interconnected due to the significant synergy between them.

We observe that a large proportion of the tracts encompass both grasslands and deciduous forests, making it cost-effective to inventory these types of habitats together. There is also a clear risk of missing several tree-covered pastures, especially those with dense canopy, if they are exclusively included in the grassland inventory. Likewise, occurrences of sparsely tree-covered pastures or those grasslands with a high proportion of coniferous trees may be overlooked if they are exclusively inventoried in the deciduous forest inventory.

Selection of Tracts and Field Plots for Field Inventory

In the grassland and deciduous forest inventories, the inventory process consists of two steps: 1) selection of tracts and 2) selection of field plots within each tract (Figure 1). The efficiency of these inventories is partially due to the fact that many areas do not require field visits. By utilizing aerial imagery, it is possible to identify areas that lack the targeted nature types, allowing the exclusion of these areas and sample plots for field inventory. However, they still remain part of the sample. As an example, in 2020, a total of 137,396 sample plots were aerially surveyed across 701 areas. Out of these, 1,763 sample plots distributed among 187 areas were visited in the field.


Figure design

Figure 1. A schematic figure of the steps involved in the sample design and how they are applied in the grassland inventory for the year 2021. In the first step, plots (A) are randomly selected from the sampling framework using a coordinated balanced selection. The sample plots within these plots are classified through remote sensing; in the grassland inventory, this involves aerial imagery inventory (B). The classes derived from remote sensing are then combined to form selection classes. In the second step, a random coordinated selection of sample plots (C) is made for field visits. In the deciduous forest inventory, deciduous forest classes are used instead to classify the sample plots. Figure modified from Ranlund & Hedenås (2023).


In the first step, tracts are randomly selected from the sampling frame using a coordinated balanced sampling approach. Subsequently, all plots within the selected tracts are classified into both deciduous forest and grassland classes based on aerial imagery. For the grassland and deciduous forest inventories, the aerial classifications are combined separately to form selection classes.

In the second step, the selection classes are used to randomly choose the plots for field inventory. The selection of plots for field visits in the grassland and deciduous forest inventories is conducted independently of each other.

The Tract

In the grassland and deciduous forest inventories, a tract (1 km × 1 km) consists of 196 circular plots with a radius of 10 m (Figure).

Inventory in aerial images

In the inventory in aerial images, potential grasslands and deciduous forests within the plots are classified based on a classification scheme. The selection of grassland and deciduous forest types to be inventoried in each sample is determined by their frequency of occurrence in the landscape. Less common habitats are inventoried in larger samples, while more common types are inventoried in smaller samples. The aerial imagery inventory is conducted jointly for both the grassland and deciduous forest inventories, allowing the aerial surveyors to observe each sample plot only once. Further details regarding the aerial imagery inventory can be found at the following page.

Selection of Plots for Field Inventories Based on Selection Classes

The classifications obtained from the inventory in aerial images, are subsequently combined to form selection classes. A random coordinated selection of field plots is then conducted based on these selection classes. The selected  plots are subjected to field inventory.

The maximum number of plots chosen to be surveyed in the field per inventory has varied during the first three years. For instance, in the year 2020, a maximum of 10  plots were selected for field visits per tract and inventory, totaling up to 20 field plots per tract for the two inventories combined. The selection was performed at the tract level, and in cases where there were more sample plots than the maximum limit of 10 per tract, the maximum limit per selection class within a tract that were potentially of interest, a subset of the field plots was chosen. The selection of  plots for field inventory within an area has been randomized, but weighted in a way that sample plots with higher-priority classes were chosen to a greater extent.



Adler, S., Christensen, P., Gardfjell, H., Grafström, A., Hagner, Å., Hedenås, H. och Ranlund, Å. 2020. Ny design för riktade naturtypsinventeringar inom NILS och THUF. Arbetsrapport 513. Sveriges lantbruksuniversitet, Institutionen för skoglig resurshushållning, Umeå. In Swedish.

Hedenås, H., Hagner, Å., Ranlund, Å., Christensen, P., Lidén, M., Gardfjell, H. och Adler, A. 2022. Vad klarar vår nya stickprovsdesign? NILS gräsmarks- och lövskogsinventeringar 2020. Arbetsrapport 531. Sveriges lantbruksuniversitet, Institutionen för skoglig resurshushållning, Umeå. In Swedish.

Ranlund, Å., Sjödin, M., Press, A., Gardfjell, H., Hedenås, H., Hagner, Å., Forsman, H., Christensen, P., Andersson, M. och Adler, S. 2021. Metodbeskrivning: 2020 års inventeringar av gräsmarker och lövskogar Arbetsrapport 530, Institutionen för skoglig resurshushållning, SLU, Umeå. In Swedish.


Henrik Hedenås, Program Manager
Department of Forest Resource Management/Division of Landscape Analysis, SLU, 090-786 86 41
